Quantum Bench- and upright drill B 32

Product No.:
300 8323
Shipping time:
3-4 days
Availability:
0
Print data sheet
Print
Wishlist

1.001,45 EUR
plus. 19 % Tax excl. Shipping costs
- +





Quantum Bench- and upright drill B 32



Convincing arguments: quality, efficiency and price

  • Guaranteed concentricity precision less than 0.03 mm measured in the drilling spindle sleeve
  • Spindle with precision ball bearings
  • Quantum high-grade quick-action drill chuck with concentricity precision less than 0.09 mm supplied as standard (from B 14 onwards)
  • Smoother running due to aluminum pulleys with ground six-tooth dog (from B 14 onwards)
  • Better power transmission due to the quality driving V-belt
  • Long, ergonomically designed lever arm handles with softgrip for nonskid working
  • Drill depth stop
  • Precision-ground work table with transversally running T-slots, swivelling from -45° to +45° with 360° rotatability
  • Solid, heavy duty base plate with T-slots, heavily ribbed at the backside
  • T-slots for holding a vice supplied as standard (from B 14 onwards)
  • 400 Volt models additional with right-left-hand rotation
  • Powerful, smooth-running electric motors (from B 14 onwards)
  • Proven quality
model quantum B 32
Item no. 300 8323
Technical data
Drilling capacity in steel (max.) 32 mm
Working range 225 mm
Distance spindle / table (max.) 600 mm
Spindle holding fixture MT 4
Spindle speeds 140 - 1980 rpm
Number of steps 9 steps
Sleeve travel 125 mm
Upright diameter 92 mm
Table size (L x W) 360 x 360 mm
T-slot size 14 mm
Drilling table swivel + / - 45°
Motor power 50 hz 1,1 kW
Dimensions (L x W x H) 790 x 400 x 1730 mm
Net weight 138 kg
