Column Drilling Machine AB 50/SV


14.294,89 EURplus 16 % tax, excl. Shipping costs



Product No.:
AB 50/SV
Shippingtime:
No longer available (abroad may vary)
Weight per unit:
450 kg



AB Series

Trendsetters for high performance drilling. Unmatched and highly precise.

Column Drilling MachineAB 50/SV


Drilling Performance in Steel E 335 St 60 50 mm
Drilling Performance in Cast-iron EN-GJL-200 60 mm
Drilling Capacity in Steel E 335 St 60 60 mm

Tapping Performance
in Steel E 335 St 60 M 42
in Cast-iron EN-GJL-200 M 60

Tool Taper (short spindle) MT 4
Distance Spindle to Column 350 mm
Table Clamping Area 720 x 510 mm
T-Slots, number x width x distance 2 x 14 x 224 mm
Distance spindle/table min./max. 138/874 mm
Column Diameter 200 mm
Z-Travel of Spindle 200 mm
Feeds 0,15-0,2-0,3-0,36 mm/Rev
Net weight approx. 605 kg
Drive system stepless with gear box
Motor 1500 / 3000 Rpm
Performance 3,6 / 4,3 kW
Spindle Rpm 60-1530 or 50-1280

Standard Equipment:

    Electro-magnetic Feed Clutch with Electrical Cross Handle Switches
    Main Switch (lockable) with Overload Circuit Breaker
    Overload Feed Clutch
    Self-Locking Mushroom Button for EMERGENCY OFF switch
    Infinitely variable speed drive
    Digital RPM Read-out
    Protection Class IP 54
    Spindle Protection, with electric security
    Grinded Base Plate with T-Slots (AB 50/SV)
    Built-in Machine Light
    Machine oil
    Lacquer: DD-structured grey RAL 7035, anthracite RAL 7016, alu RAL 9006

Options:

10. Spindle Reverse switch for Anti-clockwise rotation with 0-position (not with pos. 20.0 + 20.1)

12. Haloflex Machine Light, adjustable (Halogen 12 V/IP 64)

20.0 Tapping Attachment, (automatic reverse) w/o foot switch,
max. 6 tapped holes per minute (tapping capacity depending on Rpm speed)

20.1 Tapping Attachment, (automatic reverse) with additional foot switch,
max. 6 tapped holes per minute (tapping capacity depending on Rpm speed)

24. Coolant Attachment A*, consisting of:
Coolant Base plate with grinded surface 320 x 320 mm and 2 slots, overload-protected pump and accessories (for AB 26/SV and AB 34/SV only)

25. Coolant Attachment B separate container (33 l),
with overload-protected pump and accessories

50.6 Precision Depth Adjuster and fixed stop, precision adjustment to 0,1 mm

08. Wooden Packing w x d x h 1200 x 800 x 2100 mm Verpackungsgewicht ca. 75 kg

*) net weight increases with 80 kg
