Knuth HPS 115 S Hydraulic Structural Steel Cutters


Price on request


Product No.:
131176

Knuth HPS 115 S Hydraulic Structural Steel Cutters

Universal machining on up to 5 work stations: Punching - cutting - notching

Knuth HPS 115 S Hydraulic Structural Steel Cutters:

with hydraulic cylinders allows simultaneous operation at 2 stations

Flat Steel Cutters

  • For strip steel, flat steel, wide flat steel
  • table with angular and linear stops
  • Adjustable hold-down
  • lower knife provides 4 cutting edges

Angular Profile Steel Cutters

  • For angle steel sections
  • Cut angle 90° and 45°
  • Adjustable material guide plate

Rod Steel Station

  • For round and square steel
  • Robust material guide plate

Rear stop

  • Automatic cut activation
  • Including swivel boom
  • For use on Flat Steel, Angular Steel and Rod Steel Stations

Hole Punch Station

  • For punching round holes and slots in sheet metals, flat steel and U-section steel
  • Table with adjustable angular stops
  • Linear stop and scale
  • infinitely variable stroke adjustment
  • including adapter for "Peddinghaus" stamps and dies
  • Hydraulic overload protection

Notching Station

  • Rigid support table with adjustable stops

Specifications - Knuth HPS 115 S Hydraulic Structural Steel Cutters:





Punch press

Pressure force

Punch capacity (max.)

Diameter x thickness

Throat

Stroke

Stroke number (at 20 mm stroke)

Working height



115 t

Ø55x16 mm

34x26 mm

355 mm

80 mm

25 H/min

1.110 mm

Steel cutter

Cutting capacity flat (max. width)

Cutting capacity flat (max. thickness)

Knife length

Cutting capacity round

Cutting capacity square

Steel cutter working height





600x15 mm

380x25 mm

610 mm

55 mm

50 mm

935 mm



Profile cutter

Cutting capacity 90°

Cutting capacity 45°

Profile cutter working height



150x150x16 mm

80x10 mm

1.215 mm

Notcher

Plate thickness (max.)

Width

Depth



13 mm

60 mm

100 mm

Drive capacity

Motor rating hydraulic pump



11 kW

Measures and weights

Overall dimensions

Weight





2.040x950x2.180 mm

2.920 kg
