Knuth Folding Machine MagBend 1250


Versatile and user-friendly - with magnetic plate clamping

  • versatile and efficient with exchangeable top beams
  • easy to use magnetic clamp with a press force of 6 tons over the entire length
  • high accuracy and repeatability due to depth stops and folding angle stops with scales
  • includes extensive standard equipment for easy machining of deep containers and polygon tubes
  • top beams can be easily exchanged to produce many different bending shapes



Specifications - MagBend 1250 - Folding Machine

working area
bending length 1250 mm
bending capacity St. 42 1,6 mm
bending bar angle (range) 0 - 135 °
stop depth 640 mm
clamping force 6 t
measures and weights
overall dimensions 1320x920x930 mm
weight 220 kg


Standard equipment - MagBend 1250 - Folding Machine

plain top beam, segmented top beam, grooved top beam, rectangular top beam, foot pedal, rear stop, angle stop, operator manual
