Four side planer Holzmann VS 20/5PM


20.540,12 EURplus 16 % tax, excl. Shipping costs



Product No.:
VS 20/5PM
Shippingtime:
Weight per unit:
1650 kg
Vierseitenhobelmaschine Holzmann VS 20/5PM


- complete with 4 cutter heads
- working spindle vertically and horizontally adjustable
- fifth independent universal spindle 360° turnable (ideal for almost every profile cut)
- solid heavy and low vibration setup
- steel and cast iron machine
- very long work piece table ensures save feeding of work pieces
- chip removal steplessly adjustable up to 10mm
- clear-positioned control panel


- precise and smooth run of the work piece feeding due to a feeding roller in front of the first spindle.
- pressure on every feeding roller steplessly adjustable w/o tools
- spindle position adjustable via mechanical digital position indication (1/10 accuracy)


included in delivery: 4 cutter heads, tools, lubrication pumping system

available accessories: table extension 300/500mm



max. dimension of the work piece: 180/120 mm
min. dimension of the work piece: 16/7 mm
number of operating spindles: 5
spindle speed: 6000/min.
spindle diameter: 40 mm
standard diam. of tooling 1.2.3.4.: 120 mm
max diam. of tooling(2nd, 3rd, 4th, 5th spindle): 180 mm
feeding speeds: 6/12 m/min

feeding table length: 1700 mm (2000)
quick adjustment feeding tabel: 10 mm
horizontal spindles motor (100%): 2x 5,5 kW
vertikal spindles motor (100%): 7,5 kW
feeding motor (100%): 0,9 / 1,5 kW
total motor power (100%): 24 kW

weight: 1650 kg
