Table/bench drilling machine

Name: Table/bench drilling machine ALZTRONIC 9
Brand: Alzmetall
SKU: ALZTRONIC 9
Price: 1391.59 EUR
Availability: InStock

Main page » Metal machining » Table drilling machines » Table/bench drilling machine ALZTRONIC 9

Fast and precise small bench drilling machines in 230 V.

For laboratories and manufacturers.

With a top entrance price.

Drilling capacity steel E335 (St 60)	9 mm

Tapping capacity in steel E335 (St 60)	M 8
Exterior tapper	B 16
Z-travel of spindle	40 mm
Distance spindle to column	200 mm
Column diameter	50 mm
Machine baseplate, clamping surface (w x d)	300 x 240 mm
T-slots, number x weidth x diastance	2 x 12 x 80 mm
Distance spindle to baseplate min./max.	110/250 mm
Machine table, clamping area (w x d)	without
T-slots, number x weidth x diastance	without
Distance spindle machine table min./max.	without
Advance feed	manual
Head adjustment	Handwheel
Machine table adjustment	without
Net weight approx.	64 kg
Speed variator	stepless
Motor	0,54 kW
Spindle speeds Rpm	390-6500

Standard Equipment:

    AC Motor 230 V, 50 Hz
    Digital RPM read-out (LED)
    Infinitely variable speed setting
    Reverse switch for clockwise and anti-clockwise rotation
    Spindle protection electrically secured
    On/Off switch with lockable emergency-off cover
    3 Meters cable with connector plug installed
    Lacquer: DD-structured grey, RAL 7035,
    anthracite RAL 7016, alu RAL 9006, black
    Stable carton packing WxDxH approx. 600x510x880 mm
    Carton weight approx. 3 kg
