spare parts for Alzmetall machines ,you can request them at info@wgm-maschinen.de, to request them. Please send us a photo of the type plate or send us the type with the machine number and which spare part you require- type with machine no. and which spare part you need, You will then receive a quotation. Radial Drilling Machines RADIAL for large and heavy parts Alzmetall Schnellradialbohrmaschine Alzsprint 30 |
||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||
Standard Equipment: Self-Locking Mushroom Button for EMERGENCY OFF switch Protection class IP 54 Electromagnetic feed clutch with push button Tapping device with double return speed Clockwise rotation with contactor control Control transformer (VDE 0113) Spindle protection electrically secured Main switch lockable Central hydraulic clamping Machine light Lacquer: DD-structured grey RAL 7035, anthracite 7016 Machine oil |
||||||||||||||||||||||||||||||||
Options: 1.10 Levelling elements (1 set = 5 elements) for anchoring and levelling the basic machine 1.40 Levelling elements for the floor plate (1 set=6 elements) 2.10 Floor plate, with surrounding coolant channel, clamping surface 1000 x 1400mm, height 100mm with 4 T-slots 18mm. 2.20 T-Slot plate, vertical clamping plate with horizontal T-slots. For mounting into the vertical T-slots integrated in the machine base. Aside or at the rear side of the machine. Clamping surface 750 x 350mm. Depth 185mm, with 3 T-slots of 18mm. 2.30 Angular Table. With surrounding coolant channel. For mounting into the vertical T-slots integrated in the machine base. Aside or at the rear side of the machine. Clamping surface 800 x 600mm. Height 480mm with 4 T-slots of 18mm at a distance of 150mm. 2.40 Tilting table. Swivelling by ± 90°, clamping surface 600 x 400 mm. With 3 T-slots, width 18mm, at a distance of 125mm. Swivel adjustable by worm and wheel mechanism with crank. Maximum table load 150kg. For mounting into the vertical T-slots integrated in the machine base. Aside or at the rear side of the machine. CUBES FOR CLAMPING WORKPIECES: 2.60 Cubic work table with 2 Clamping surfaces; upper side 550 x 550 mm, vertical side 550 x 500 mm. 2.70 Cubic work table with 2 Clamping surfaces; upper side 1000 x 755 mm, vertical side 1000 x 500 mm. TILTING 0-90° CUBES FOR CLAMPING WORKPIECES: 2.80 Cubic work table with 2 Clamping surfaces; upper side 550 x 550 mm, vertical side 550 x 410 mm. 2.90 Cubic work table with 2 Clamping surfaces; upper side 750 x 600 mm, vertical side 750 x 410 mm. 3.15 Positions-Assistenfunktion (Details siehe Beschreibung) 10.10 Coolant system A, integrated in the machine base, for machines without a floor plate, consisting of: Coolant tank, with a content of 25 l, coolant pump, with complete fittings. 10.40 Separate coolant recirculation for floor plates (under-floor size approx. 300 x 200 x 200 mm) (provided: Coolant system A, Pos. 10.20 is installed) Packing: large wooden support bars w/o charge |
