Bernardo SP 500 surface planing machine

Product No.:
SP 500
Shippingtime:
1-3 Weeks (abroad may vary)
Weight per unit:
570 kg
8.382,70 EURplus 19 % tax, excl. Shipping costs
Bernardo SP 500 surface planing machine

Bernardo SP 500 surface planing machine

The surface planing machines of the SP-Series with the advanced technic, the heavy and vibration-free construction and the high operation convenience fulfil the requirements of the professional user.
SP 400
Planing width 405 mm
Table length 2480 mm
Table height 800 mm
Left planer table length 1330 mm
Right planer table length 1140 mm
Planer fence 1100 x 170 mm
Cutter knives 4 pcs.
Planer shaft diam. 110 mm
Shaft rotation speed 5000 rpm
Max. planing thickness 8 mm
Dust extractor outlet 125 mm
Motor power 3,75 kW (5,0 HP)
Weight approx. 570 kg
SP 500
Planing width 508 mm
Table length 2850 mm
Table height 800 mm
Left planer table length 1452 mm
Right planer table length 1256 mm
Planer fence 1100 x 170 mm
Cutter knives 4 pcs.
Planer shaft diam. 110 mm
Shaft rotation speed 5000 rpm
Max. planing thickness 8 mm
Dust extractor outlet 125 mm
Motor power 3,75 kW (5,0 HP)
Weight approx. 730 kg
  • Ground planer tables with precise routed parallelogram-system
  • Tiltable planer fence (90° - 45°) with tolerant area of support
  • Robust and low-vibration stand for vibration-free work
  • Comfortable adjustment of the max. planing thickness using a handwheel
  • Tolerant dimensioned electric-panel on the up side of the machine
  • The parallelogram-adjustment guaranteed a constant distance between table and cutterblock
  • Standard with suction hood diam. 125 mm, safety protection and planer fence
  • The planer tables are with toothed table lips for noise reduction
  • Best planing results through the untroubled run of the precision 4-knive cutterblock
  • Smooth run trough precision bedded cutterblock
